PERFORMANCE CHARACTERISTICS OF M35 CAPACITORS
ELECTRICAL CHARACTERISTICS
Vishay
ITEM
Operating temperature range
Capacitor tolerance
Capacitance change (maximum)
ESR
AC ripple current
DCL (maximum leakage current)
Impedance (maximum)
Reverse voltage
Surge voltage
Life test
PERFORMANCE CHARACTERISTICS
- 55 °C to + 125 °C
± 20 %, ± 10 % at 120 Hz
Limits per Standard Ratings table. Measured per requirements of MIL-PRF-39006.
Reverse voltage shall be in accordance with MIL-PRF-39006/22.
Units are capable of withstanding 3 V in reverse at + 85 °C for 125 h.
Surge voltage shall be in accordance with MIL-PRF-39006.
The DC rated surge voltage is the maximum voltage to which the capacitors should be subjected
under any conditions. This includes transients and peak ripple at the highest line voltage. The
surge voltage is 115 % of rated DC working voltage.
The capacitors shall be capable of withstanding a 2000 h life test at 85 °C at rated voltage.
ENVIRONMENTAL CHARACTERISTICS
ITEM
CONDITION
COMMENTS
Hermeticity
Moisture resistance
Altitude/barometric pressure
(reduced)
MIL-PRF-39006
MIL-PRF-39006
MIL-PRF-39006
The internal component has been tested to be compliant to
hermeticity requirements of MIL-PRF-39006/22.
The internal component has been tested to be compliant to
moisture resistance requirements of MIL-PRF-39006/22.
The internal component has been tested to be compliant to
altitude or reduced barometric pressure requirements
the
the
the
of
MIL-PRF-39006/22 (150 000 feet).
MECHANICAL CHARACTERISTICS
ITEM
Thermal shock
Shock
Vibration (high frequency)
Vibration (random)
Resistance to solder heat
Solderability
Part markings
Weight (typical) in g
CONDITION
MIL-STD-202, Method 107, A
MIL-STD-202, Method 213
MIL-STD-202, Method 204
MIL-STD-202, Method 214
MIL-STD-202, Method 210
ANSI J-STD-002
MIL-STD-1285
3.5
COMMENTS
Per MIL-PRF-39006, 30 cycles
Per MIL-PRF-39006, 500 g
Per MIL-PRF-39006, 80 g
Per MIL-PRF-39006, 53.79 g
The capacitor must withstand solder dipping of the terminals at
260 °C for 10 s. The capacitor must not be visibly damaged and the
electrical characteristics must not be affected.
The terminations must be solderable per the requirements of
MIL-PRF-55365 para. 4.10
The part marking shall include Vishay name, trademark,
capacitance, voltage, date code and lot symbol.
PAD DIMENSIONS in millimeters
A
C
B
C
CASE CODE
C
A (MIN.)
22.7
B (NOM.)
14.7
C (NOM.)
4.0
D (NOM.)
6.4
STANDARD PACKAGING QUANTITY
SERIES
M35
Revision: 07-Nov-11
CASE CODE
C
4
BULK/TUBE
10 pcs
Document Number: 40095
For technical questions, contact: tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
